Air Inlet
- 1/4″ FNPT
Liquid Inlet
- 1/4″
Liquid Discharge
- 1/4″
Connection Type
- FNPT/FBSPT (Threaded)
Max Suction Lift Capability
- 14 ft-H2O (4.2 m-H2O) Dry
- 28 ft-H2O (8.5 m-H2O) Wet
Specifications
| Physical Specifications | ||
|---|---|---|
| Liquid Port Size: | 1/4 in. | |
| Liquid Connection Types: | FNPT (FBSPT) | |
| Standard Suction Port: | Right | |
| Standard Discharge Port: | Right | |
| Air Inlet Connection Size: | 1/4 in. FNPT | |
| Air Exhaust Connection Size: | 1/4 in. FNPT | |
| Polypropylene | PVDF | |
| Max Height: | 6.8 in. (173 mm) | 6.8 in. (173 mm) |
| Max Width: | 7.3 in. (186 mm) | 7.3 in. (186 mm) |
| Max Depth: | 4.8 in. (123 mm) | 4.8 in. (123 mm) |
| Weight: | 2.6 lbs (1.2 kg) | 3.8 lbs (1.7 kg) |
| Construction | |
|---|---|
| Wet End: | Polypropylene, PVDF |
| Air End: | Polypropylene |
| Diaphragm: | Bunalast™, PTFE, Santoprene® |
| Balls: | Bunalast™, PTFE, Santoprene® |
| Seats: | Polypropylene, PVDF |
| O-Rings: | Buna-N, EPDM, PTFE, FKM |
| Hardware: | PTFE Coated Stainless Steel, Stainless Steel |
| Muffler: | Plastic |
Performance
Performance Curve
Note:Â Additional performance curves can be found in the download section.
| Performance | |
|---|---|
| Max Flow: | 5.7 gpm (21.6 lpm) |
| Max Air Pressure: | 120 psi (8.2 bar) |
| Max Static Suction Head: | 23 ft-H2O (7.0 m-H2O) |
| Max Suction Lift (Dry): | 14 ft-H2O (4.2 m-H2O) |
| Max Suction Lift (Wet): | 28 ft-H2O (8.5 m-H2O) |
| Max Solids: | 1/16 in. (1.6 mm) |
| Avg. Displacement Per Stroke: | (0.01 gal / 0.04 L) |
| Sound Level: | 80 dBA (with Muffler |
