B50 Non-Metallic
B50 Non-Metallic - Image 2
B50 Non-Metallic - Image 3

B50 Non-Metallic

  • Simple construction, easy to maintain
  • Capable of handling high S.G. and viscous fluids
  • Pressures to 8.6 bar (125 PSI)
  • Flow rates up to 530 litres/minute (140 gal/min)
  • Flanged end connections
  • Reliable, proven pneumatic air valve

Interested in our products? Connect with us easily! Simply scan the QR code or click the link to reach us on Line. We’re here to help with any questions or orders!

QR Code
Category:

Specifications

  • Maximum Delivery 530 ltrs/min (140 gal/min)
  • Max. Working Pressure 8.6 bar (125 PSI)
  • Max. Solid Particle Size 6 mm. (0.24″)
  • Air Inlet 3/4″ NPT
  • Temperature Limits Determined by Elastomers
  • Suction Lift (Dry) 6.1 metres (20 feet)
  • Suction Lift (Wet) 7.6 metres (24.9 feet)
  • Fluid Inlet / Outlet 2″ ANSI #150 Flanged RF
  • Installation Surface mounted
  • Accessories Included Exhaust Air Silencer
  • Shipping Weight 39.5 kg. (87.1 lbs) polypropylene / aluminum 50.5 kg. (111.3 lbs) PVDF / aluminum 50.5 kg. (111.3 lbs) polypropylene / stainless steel 70 kg. (154.3 lbs) PVDF / stainless steel
  • Shipping Dimensions 630 x 380 x 670 mm 24.8″ x 15.0″ x 26.4
